There is no universal table-saw pulley. A replacement has to match the shaft it mounts on (motor or arbor), the belt section, the original pulley diameter and the available clearance; changing diameter also changes blade speed. Measure the shaft and keyway with the saw unplugged, read the motor and saw manuals, and retain the manufacturer’s intended speed range. The general-purpose sheaves below are only candidates after those checks—not claimed direct replacements for any saw.
| # | Product | Price | Where to buy |
|---|---|---|---|
| 1 | USA Roller Chain AK25-5/8 Pulley | $13–$20 | Amazon |
| 2 | VXB AK25-5/8 Cast-Iron Pulley | $50–$65 | Amazon · eBay |
| 3 | VXB BK25-5/8 Cast-Iron Pulley | $25–$35 | Amazon |
| 4 | VXB AK3058 Cast-Iron Sheave | $50–$65 | Amazon |
| 5 | VXB 3-inch 5/8-inch-Bore Motor Pulley | $45–$55 | Amazon |
| 6 | VXB Fixed-Bore 2.50-inch A/AX Pulley | $20–$30 | Amazon |
| 7 | Rubber Belts Online 2AK25-5/8 | $35–$45 | Amazon |
| 8 | Burr King 725 V-Belt Pulley | $20–$40 | Amazon |
| 9 | AK30-5/8 Cast-Iron Sheave | $40–$65 | Amazon · eBay |
The picks, in detail
USA Roller Chain AK25-5/8 Pulley
General-sheave near-miss: a 2.50-inch, 5/8-inch-bore A-belt pulley; use only if those measurements match the motor or arbor drive.
- 2.50-inch diameter
- 5/8-inch bore
- A-belt section
- Published dimensions
- grade-35 cast iron
- Not saw-specific
- verify keyway and speed
VXB AK25-5/8 Cast-Iron Pulley
General-sheave near-miss with one groove, 2.5-inch OD and 5/8-inch bore; its listed keyway is 1/4 by 1/8 inch.
- 2.5-inch OD
- 5/8-inch bore
- one groove
- keyway listed
- set screws included
- not a direct saw part
- belt section must match
VXB BK25-5/8 Cast-Iron Pulley
General-sheave near-miss: single-groove 2.5-inch pulley for 4L/5L belts, with a 5/8-inch bore, keyway and hex set screws.
- 2.5-inch OD
- 4L/5L groove
- 5/8-inch bore
- set screws
- cast iron
- not for every belt profile
- confirm shaft role
VXB AK3058 Cast-Iron Sheave
General-sheave near-miss: one-groove 3-inch OD, 5/8-inch-bore cast-iron sheave for 3L, 4L or 5L belts, with keyway and set screw.
- 3-inch OD
- 5/8-inch bore
- 3L/4L/5L
- through-bore length published
- keyway included
- changes ratio versus 2.5-inch pulley
- not saw-specific
VXB 3-inch 5/8-inch-Bore Motor Pulley
A one-groove cast-iron 3-inch pulley listed for A, 3L and 4L belts, with a 3/16 by 3/32-inch keyway and two screws.
- 3-inch OD
- 5/8-inch bore
- 3/16 by 3/32 keyway
- motor-pulley form
- two screws listed
- measure motor shaft
- not for toothed belts
VXB Fixed-Bore 2.50-inch A/AX Pulley
General-sheave near-miss: fixed-bore, single-groove cast-iron pulley with 5/8-inch bore for A/AX, 3L and 4L belts.
- 2.50-inch OD
- fixed 5/8-inch bore
- A/AX groove
- broad listed belt compatibility
- cast iron
- no universal arbor fit
- inspect original ratio
Rubber Belts Online 2AK25-5/8
General-sheave near-miss with two grooves rather than the usual single belt: 2.5-inch OD, 5/8-inch bore, 1/4 by 1/8 keyway and two set screws.
- two grooves
- 2.5-inch OD
- 5/8-inch bore
- keyway specified
- set screws specified
- two-groove design may not clear
- not a saw OEM pulley
Burr King 725 V-Belt Pulley
General-sheave near-miss: a 2.5-inch-OD, 5/8-inch-ID V-belt pulley. Confirm its groove, hub offset and retention details before considering it.
- 2.5-inch OD
- 5/8-inch ID
- V-belt pulley
- simple published size
- industrial supplier
- full fitment must be checked
- not saw-specific
AK30-5/8 Cast-Iron Sheave
General-sheave near-miss: a 3-inch OD, 5/8-inch-bore single sheave with hex set screw and keyway for 3L/4L/5L belts.
- 3-inch OD
- single groove
- cast iron
- set screw
- keyway
- speed ratio changes
- verify motor versus arbor shaft
Buying tips
- Photograph and measure the original pulley, shaft, keyway, belt and hub offset before ordering.
- Do not substitute a motor pulley for an arbor pulley simply because the bore matches.
- Keep guards in place and do not exceed the saw, motor, belt or pulley speed rating.
